Why Rotary Gear Pumps for Food & Beverage Transfer
Food and beverage production demands pumps that can handle a wide range of viscosities — from thin fruit juices and flavor concentrates to thick syrups, chocolate, and pastes. NAPCO rotary gear pumps deliver consistent, predictable flow across this entire range, with the positive displacement design ensuring accurate volume output regardless of viscosity changes during processing.
Our 316 stainless steel construction provides excellent corrosion resistance and is well-suited for food-grade fluid handling. The self-priming design draws product directly from drums, totes, tanks, and kettles without external priming equipment, reducing downtime between product changeovers.
316 Stainless Steel Construction
Corrosion-resistant housings and wetted parts suited for food-grade fluids, syrups, and acidic products.
Self-Priming
Draws product directly from tanks, kettles, and drums — no external priming or vacuum assist needed.
Bi-Directional Operation
Forward and reverse flow from a single pump. Load, unload, and transfer product without re-plumbing lines.
Gentle Product Handling
Low-shear positive displacement action preserves product consistency and quality during transfer.
Stainless Steel Construction for Food-Grade Applications
NAPCO stainless steel pumps are built with 316 SS housings that resist corrosion from acidic juices, brine solutions, and cleaning agents used in food production environments. The alloy steel shaft and precision-machined components maintain tight tolerances for consistent, repeatable flow rates batch after batch.
Standard nitrile rubber gears (rated to 240°F) work well for most food-grade fluids. For high-temperature applications like hot chocolate, warm syrups, or heated oil transfer, Viton gears are available and rated for extended service at elevated temperatures.
Recommended Pumps for Food & Beverage Transfer
PA300S — 3″ Stainless Steel
High-capacity stainless steel pump for production-scale food processing — syrup transfer, oil handling, and bulk ingredient movement.
| Max Flow | 158 GPM @ 280 RPM |
| Max Pressure | 100 PSI |
| Housing | 316 Stainless Steel |
| Gears | Nitrile or Viton |
| Weight | 148 lbs |
PA200S — 2″ Stainless Steel
Compact stainless steel pump for smaller batch runs, flavor dosing, and applications where space is limited on the production floor.
| Max Flow | 69 GPM @ 190 RPM |
| Max Pressure | 100 PSI |
| Housing | 316 Stainless Steel |
| Gears | Nitrile or Viton |
| Weight | 83 lbs |
Ductile iron versions (PA300C, PA200C) available for non-corrosive food-grade applications where cost-effectiveness is a priority.
Food & Beverage Applications
- —Syrups & sweeteners — Corn syrup, maple syrup, molasses, sugar solutions, and liquid sweetener transfer in confectionery and beverage production.
- —Edible oils & fats — Vegetable oil, palm oil, coconut oil, shortening, and cooking fat transfer between storage and processing equipment.
- —Chocolate & confectionery — Warm chocolate, cocoa butter, caramel, and candy coatings transferred at controlled temperatures during production.
- —Flavorings & extracts — Concentrated flavor oils, vanilla extract, and food-grade colorants for batching and blending operations.
- —Sauces & condiments — Ketchup, mustard, mayonnaise, salad dressings, and other viscous food products in packaging and filling lines.
Related Technical Resources
Stainless Steel vs. Ductile Iron
Compare housing materials to determine the best fit for your food-grade application.
Nitrile vs. Viton Gears
Gear material selection guide — when to choose nitrile vs. Viton based on temperature and chemical compatibility.
How to Size a Rotary Gear Pump
Step-by-step sizing guide covering flow rate, viscosity, pressure, and RPM calculations.
Need a pump for food or beverage transfer?
Tell us about your product — viscosity, temperature, flow requirements — and we'll recommend the right NAPCO pump and gear combination for your application.
Request a Quote
